Studio Reference Amplifier

Tech Spec –
FREQUENCY RESPONSE: 20Hz-20kHz +/- 0.5dB
OUTPUT POWER: 
200W at 8 ohms
300W at 4 ohms
500W bridged into 8 ohms
DISTORTION: <0.05%
SIGNAL TO NOISE: >94dB
INPUT IMPEDANCE: (Balanced) 20KΩ (Unbalanced) 10kΩ
DAMPING FACTOR (100HZ, 8Ω): 250
SIGNAL TO NOISE RATIO (A WEIGHTED): >103DB
AMPLIFIER: CLASS AB
SLEW RATE (AT 1KHZ): 28V/US
INPUT SENSITIVITY (1KHZ): 0.775V (0DBU)
TOTAL HARMONIC DISTORTION (1KHZ): ＜0.1%
INTERMODULATION DISTORTION (AT 10% RATED POWER 1KHZ): ＜0.1%
CROSSTALK: -70DB
8Ω STEREO POWER (1KHZ): 200W
4Ω STEREO POWER (1KHZ): 300W
8Ω BRIDGE POWER (1KHZ): 500W
CABINET DIMENSIONS: 19”W X 18”D X 3.5”H 30.4 LBS
WEIGHT: 20KG (44LB)
