Studio Monitors
Powered
Nearfield (0.5m-2m)
2 way
4”LF
88Hz cut off
106 dB per pair

Tech Spec –
Dimensions: 132(w) x 262(h) x 160(d) mm / 5.1″(w) x 10.3″(h) x 6.2″(d)
Weight: 3.5kg / 7.7lb
Drivers: Low Frequency 1 x 100mm(4″) LF
High Frequency: soft dome – 1 x 28mm (1. 1/8″)
Maximum SPL: 100 dB continuous pink noise @ 1m Leq 1 minute. 106 dB per pair continuous pink noise @ 1m Leq 1 minute
Frequency Response: 100 Hz – 19 kHz ± 2dB / 88 Hz -6 dB
INPUT
Connector: XLR and ¼ inch Jack combo socket
Impedance: 10k ohm Electronically balanced
Wiring: Pin 1 ground, Pin 2 hot, Pin 3 cold
Sensitivity: TBC
FILTERS
Protective lower filter : -3dB @ 45Hz, 24dB/oct
Protective upper filter : -3dB @30kHz, 24dB/oct
Crossover Point: 1k67H
