Studio Monitors
Powered
Nearfield (0.5m-2m)
2 way
8”LF
38 Hz Cut Off
114.5dB per pair

Specifications
Dimensions: 340 x 400 x 365mm (w x h x d)
Weight: 23kg / 50.5lb
Drivers: Low Frequency 1 x 200mm(8″) LF
High Frequency: soft dome – 1 x 28mm (1. 1/8″)
Maximum SPL: 108.5 dB continuous pink noise @ 1m Leq 1 minute. 114 dB per pair continuous pink noise @ 1m Leq 1 minute
Frequency Response: 45 Hz – 20 kHz ± 2dB / 38 Hz- 22 kHz -6 dB
INPUT
Connector: XLR3 type-Female
Impedance: 10k Electronically balanced with RF filters
Wiring: Pin 1 ground, Pin 2 hot, Pin 3 cold
Sensitivity: Rear mounted 10 position rotary switch calibrated in 2dB steps
Minimum sensitivity +7dBu for 100dB SPL @ 1m
Maximum sensitivity -11dBu for 100 dB SPL @ 1m
FILTERS
Subsonic: -3dB @ 20Hz, 24dB/oct
Crossover Point: 1k4H, 24dB/oct
User LF EQ: 4 position rear mounted selector to select FLAT for normal use. -3/- 9dB for cut below 40Hz, 0, +1dB.
User HF EQ 3 position rear mounted switch to select FLAT for normal use, CUT/LIFT +/-1dB above 2k5Hz.
