• Microphone amplifier

• flat frequency response

• very low harmonic distortion and noise

• works with 12V and 48V phantom power

• balanced, low-impedance output

• high suppression of interference on the microphone cable

• excellent protection against high-frequency radio interference with "RFI Shield"

• frequency-independent impedance

• signal transmission possible over very long cables

• reliable operation even with weak phantom power

• symmetrical, transformer- and capacitor-free output stage with a class-A amplifier

• above 20 kHz, the signal is attenuated for protection against interference in the ultrasonic range, e.g. through the ultrasonic autofocus of a film camera

Tech Spec –

Maximum sound pressure level (THD < 0.5 %) :with MK 4: 131 dB-SPL (P48, P12)

Frequency range :20 Hz - 20 kHz

Sensitivity :see corresponding capsule

Maximum output voltage :1 V (0 dBV) with 1 kΩ load

Low cut filter :20 Hz, 12 dB/oct.

Minimum recommended load impedance :1 kΩ

Output impedance :42 Ω

Maximum cable length :> 400 m / ~1300ft

SCHOEPS RFI Shield :Yes

Powering standard / Valid range :P48 / 20-52 V
P12 / 10-13 V

Current consumption :4 mA (P48)
8 mA (P12)

Common mode rejection ratio (at 1 kHz) :> 55 dB

Output :XLR-3M, analog, 1 channel

Length :116 mm / ~4,5"

Diameter :20 mm / ~0,8"

Weight :60 g / 2,1 oz

Surface finish :matte gray
custom color: nickel, chromagreen
